Chimera7 Pro V2 O3 GPS

Über

Beschreibung

Smooth and Powerful XING2 Motors
The latest upgrade of our bestseller XING motors, no compromises taken! Durable unibell (one-piece bell) technology, strong titanium alloy shaft with reinforced bell joint, crash resistant 7075 aluminum bell, smooth and long-lasting Japanese NSK bearings, center slotted N52H curved arc magnets and our XING O-ring bushing gap protection.
Latest Chimera7 Pro Frame for Maximum Protection
The old days are over, getting your electronics full of dirt and wet grass every time you crash. Our latest frame reduces contamination that could build up on your flight controller or ESCs, preventing failure or short circuits. Strategic airflow to keep your components cool and clean without taking any shortcuts in weight or performance. Illuminated side panels and 360-degree TPU protective parts.
DJI O3 HD Air Unit Low-Latency Digital Transmission
Up to 10 km video transmission range, enjoy a crisp and smooth real-time view in your goggles, even in environments with interference. (Source DJI)
4K Stabilized Video with 155° Ultra-Wide Angle
Together with high-grade imaging performance, it delivers exceptional visuals that will keep your audience on the edge of their seats. (Source DJI)
Secured Battery Plug with Anti-Spark Filter
Plugging in a battery can create a loud spark at the connector which is caused by the high battery current rushing into the low ESR capacitor first as well as filling up ESC capacitance. We’ve added a protective circuit to extend the lifespan of XT60 connectors and prevent rapid voltage or current spikes which can protect your electronics from damage.
Specially Designed Heatsink for DJI O3 HD Air Unit
Improved cooling performance for the high power draw of the DJI O3 video transmitter. We’ve added a custom CNC heatsink for excellent heat dissipation without overheating, even on high power levels.
GPS Pre-Installed for More Safety at A Distance
GPS functionality to find your way back and Betaflight GPS Rescue mode ready to setup (default OFF to prevent unexpected behaviour; Setup instructions included). Custom iFlight 100mm LR antenna for best signal coverage even at long distances.



Specifications:
Product Name: Chimera7 Pro V2 6S HD
FC: BLITZ F722 Flight Controller
ESC: BLITZ E55 4-IN-1 2-6S 55A ESC
Video Transmission: DJI O3 Air Unit
Frame: 327mm wheelbase
Motor: XING2 2809 1250KV motors
Prop: 7.5X3.7X3 propellers
Weight: 725g(Without Battery)
Model: Chimera7 Pro
Takeoff Weight incl. 8000mAH: Approx. 1619±10g
Takeoff Weight incl. 3300mAH: Approx. 1165±10g
Dimensions (L×W×H)：270x199x34mm
Max Speed: 140km/h
Maximum Takeoff Altitude: 7000 m
Max Hover Time: Approx. 30 mins
Max Flight Distance: 18 km
Operating Temperature Range: -10° to 40° C (14° to 104° F)
Transmission Power (EIRP): FCC: < 33 dBm / CE: < 14 dBm / SRRC: < 30 dBm Antennas: Dual Antennas (DJI O3 Air Unit) / Single Antenna (Runcam Link WASP) GNSS: GPS+SBAS+Galileo+QZSS+Glonass   Packing List: 1 x Chimera7 Pro V2 6S HD 2 x Battery pad 2 x 7.5 inch Prop(Pairs) 2 x Battery strap 1 x Screw bag   Notice: All iFlight BNFs are tested before shipment to guarantee highest quality.  If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Eigenschaften Size 7.5 inch Geometry DeadCat Flight Stack BLITZ F7/E55 Motors 2809 1250KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS M10 chipset Max. Speed 140 km/h Weight ca. 725g (without battery) Beschreibung Smooth and Powerful XING2 Motors The latest upgrade of our bestseller XING motors, no compromises taken! Durable unibell (one-piece bell) technology, strong titanium alloy shaft with reinforced bell joint, crash resistant 7075 aluminum bell, smooth and long-lasting Japanese NSK bearings, center slotted N52H curved arc magnets and our XING O-ring bushing gap protection. Latest Chimera7 Pro Frame for Maximum Protection The old days are over, getting your electronics full of dirt and wet grass every time you crash. Our latest frame reduces contamination that could build up on your flight controller or ESCs, preventing failure or short circuits. Strategic airflow to keep your components cool and clean without taking any shortcuts in weight or performance. Illuminated side panels and 360-degree TPU protective parts. DJI O3 HD Air Unit Low-Latency Digital Transmission  Up to 10 km video transmission range, enjoy a crisp and smooth real-time view in your goggles, even in environments with interference. (Source DJI) 4K Stabilized Video with 155° Ultra-Wide Angle Together with high-grade imaging performance, it delivers exceptional visuals that will keep your audience on the edge of their seats. (Source DJI) Secured Battery Plug with Anti-Spark Filter Plugging in a battery can create a loud spark at the connector which is caused by the high battery current rushing into the low ESR capacitor first as well as filling up ESC capacitance. We’ve added a protective circuit to extend the lifespan of XT60 connectors and prevent rapid voltage or current spikes which can protect your electronics from damage. Specially Designed Heatsink for DJI O3 HD Air Unit Improved cooling performance for the high power draw of the DJI O3 video transmitter. We’ve added a custom CNC heatsink for excellent heat dissipation without overheating, even on high power levels. GPS Pre-Installed for More Safety at A Distance GPS functionality to find your way back and Betaflight GPS Rescue mode ready to setup (default OFF to prevent unexpected behaviour; Setup instructions included). Custom iFlight 100mm LR antenna for best signal coverage even at long distances.     Specifications: Product Name: Chimera7 Pro V2 6S HD FC: BLITZ F722 Flight Controller ESC: BLITZ E55 4-IN-1 2-6S 55A ESC Video Transmission: DJI O3 Air Unit Frame: 327mm wheelbase Motor: XING2 2809 1250KV motors Prop: 7.5X3.7X3 propellers Weight: 725g(Without Battery) Model: Chimera7 Pro Takeoff Weight incl. 8000mAH: Approx. 1619±10g Takeoff Weight incl. 3300mAH: Approx. 1165±10g Dimensions (L×W×H)：270x199x34mm Max Speed: 140km/h Maximum Takeoff Altitude: 7000 m Max Hover Time: Approx. 30 mins Max Flight Distance: 18 km Operating Temperature Range: -10° to 40° C (14° to 104° F) Transmission Power (EIRP): FCC: < 33 dBm / CE: < 14 dBm / SRRC: < 30 dBm Antennas: Dual Antennas (DJI O3 Air Unit) / Single Antenna (Runcam Link WASP) GNSS: GPS+SBAS+Galileo+QZSS+Glonass   Packing List: 1 x Chimera7 Pro V2 6S HD 2 x Battery pad 2 x 7.5 inch Prop(Pairs) 2 x Battery strap 1 x Screw bag   Notice: All iFlight BNFs are tested before shipment to guarantee highest quality.  If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Eigenschaften Size 7.5 inch Geometry DeadCat Flight Stack BLITZ F7/E55 Motors 2809 1250KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS M10 chipset Max. Speed 140 km/h Weight ca. 725g (without battery)
